AFF鍍銀高溫電纜:具有優良的耐腐蝕性能，抗油、強酸、強堿、強氧化劑等，具有優良的電氣J緣性能，耐高電壓，高頻損耗小，不吸潮，J緣電阻大；具有優良的耐燃、耐老化性能，使用壽命長。
產品型號：AFF
執行標準：Q/IRMV1－2008
產品特性：
1、額定電壓：300/500V
2、工作溫度：-60～+200℃/250℃
3、導 體：絞合鍍錫或鍍銀銅線
4、J 緣：FEP（200℃）或PFA（250℃）鐵氟龍
5、護 套：FEP（200℃）或PFA（250℃）鐵氟龍
6、顏 色：紅/黃/蘭/白/黑/黃綠/棕/綠等
AFF鍍銀高溫電纜產品技術參數
|
芯數×截面 （mm2） |
導體結構 根數/線徑 |
J緣 |
護套 |
20℃時導體直流電阻（Ω/km） |
||
|
厚度 |
外徑 |
厚度 |
外徑 |
|||
|
2×0.12 |
7/0.15 |
0.20 |
0.85 |
0.25 |
2.20 |
150 |
|
3×0.12 |
7/0.15 |
0.20 |
0.85 |
0.25 |
2.30 |
150 |
|
4×0.12 |
7/0.15 |
0.20 |
0.85 |
0.25 |
2.60 |
150 |
|
5×0.12 |
7/0.15 |
0.20 |
0.85 |
0.25 |
2.80 |
150 |
|
6×0.12 |
7/0.15 |
0.20 |
0.85 |
0.25 |
3.10 |
150 |
|
7×0.12 |
7/0.15 |
0.20 |
0.85 |
0.30 |
3.15 |
150 |
|
2×0.2 |
7/0.20 |
0.20 |
1.0 |
0.25 |
2.50 |
83.5 |
|
3×0.2 |
7/0.20 |
0.20 |
1.0 |
0.25 |
2.60 |
83.5 |
|
4×0.2 |
7/0.20 |
0.20 |
1.0 |
0.25 |
2.90 |
83.5 |
|
5×0.2 |
7/0.20 |
0.20 |
1.0 |
0.25 |
3.20 |
83.5 |
|
6×0.2 |
7/0.20 |
0.20 |
1.0 |
0.30 |
3.60 |
83.5 |
|
7×0.2 |
7/0.20 |
0.20 |
1.0 |
0.30 |
3.60 |
83.5 |
|
19×0.2 |
7/0.20 |
0.20 |
1.0 |
0.40 |
5.80 |
83.5 |
|
2×0.35 |
19/0.16 |
0.25 |
1.30 |
0.25 |
3.10 |
49.5 |
|
3×0.35 |
19/0.16 |
0.25 |
1.30 |
0.25 |
3.20 |
49.5 |
|
4×0.35 |
19/0.16 |
0.25 |
1.30 |
0.25 |
3.65 |
49.5 |
|
5×0.35 |
19/0.16 |
0.25 |
1.30 |
0.30 |
4.10 |
49.5 |
|
6×0.35 |
19/0.16 |
0.25 |
1.30 |
0.30 |
4.50 |
49.5 |
|
7×0.35 |
19/0.16 |
0.25 |
1.30 |
0.30 |
4.50 |
49.5 |
|
19×0.35 |
19/0.16 |
0.25 |
1.30 |
0.40 |
7.30 |
49.5 |
|
2×0.5 |
19/0.18 |
0.25 |
1.40 |
0.25 |
3.30 |
36.0 |
|
3×0.5 |
19/0.18 |
0.25 |
1.40 |
0.25 |
3.40 |
36.0 |
|
4×0.5 |
19/0.18 |
0.25 |
1.40 |
0.30 |
4.0 |
36.0 |
|
5×0.5 |
19/0.18 |
0.25 |
1.40 |
0.30 |
4.40 |
36.0 |
|
6×0.5 |
19/0.18 |
0.25 |
1.40 |
0.30 |
4.80 |
36.0 |
|
7×0.5 |
19/0.18 |
0.25 |
1.40 |
0.30 |
4.80 |
36.0 |
|
19×0.5 |
19/0.18 |
0.25 |
1.40 |
0.50 |
8.0 |
36.0 |
|
2×0.75 |
19/0.23 |
0.25 |
1.70 |
0.30 |
4.0 |
22.7 |
|
3×0.75 |
19/0.23 |
0.25 |
1.70 |
0.30 |
4.0 |
22.7 |
|
4×0.75 |
19/0.23 |
0.25 |
1.70 |
0.30 |
4.70 |
22.7 |
|
5×0.75 |
19/0.23 |
0.25 |
1.70 |
0.35 |
5.30 |
22.7 |
|
6×0.75 |
19/0.23 |
0.25 |
1.70 |
0.35 |
5.80 |
22.7 |
|
7×0.75 |
19/0.23 |
0.25 |
1.70 |
0.35 |
5.80 |
22.7 |
|
19×0.75 |
19/0.23 |
0.25 |
1.70 |
0.50 |
9.50 |
22.7 |
|
2×1 |
19/0.26 |
0.25 |
1.80 |
0.30 |
4.20 |
19.0 |
|
3×1 |
19/0.26 |
0.25 |
1.80 |
0.35 |
4.30 |
19.0 |
|
4×1 |
19/0.26 |
0.25 |
1.80 |
0.35 |
5.10 |
19.0 |
|
5×1 |
19/0.26 |
0.25 |
1.80 |
0.35 |
5.60 |
19.0 |
|
6×1 |
19/0.26 |
0.25 |
1.80 |
0.40 |
6.20 |
19.0 |
|
7×1 |
19/0.26 |
0.25 |
1.80 |
0.40 |
6.20 |
19.0 |
|
8×1 |
19/0.26 |
0.25 |
1.80 |
0.40 |
6.80 |
19.0 |
|
19×1 |
19/0.26 |
0.25 |
1.80 |
0.60 |
10.20 |
19.0 |
|
2×1.5 |
19/0.32 |
0.30 |
2.25 |
0.35 |
5.20 |
11.7 |
|
3×1.5 |
19/0.32 |
0.30 |
2.25 |
0.35 |
5.30 |
11.7 |
|
4×1.5 |
19/0.32 |
0.30 |
2.25 |
0.40 |
6.20 |
11.7 |
|
5×1.5 |
19/0.32 |
0.30 |
2.25 |
0.40 |
6.80 |
11.7 |
|
6×1.5 |
19/0.32 |
0.30 |
2.25 |
0.40 |
7.50 |
11.7 |
|
7×1.5 |
19/0.32 |
0.30 |
2.25 |
0.40 |
7.60 |
11.7 |
|
19×1.5 |
19/0.32 |
0.30 |
2.25 |
0.60 |
12.5 |
11.7 |
|
2×2.5 |
19/0.41 |
0.40 |
2.80 |
0.40 |
6.40 |
6.86 |
|
3×2.5 |
19/0.41 |
0.40 |
2.80 |
0.40 |
6.40 |
6.86 |
|
4×2.5 |
19/0.41 |
0.40 |
2.80 |
0.40 |
7.60 |
6.86 |
|
5×2.5 |
19/0.41 |
0.40 |
2.80 |
0.50 |
10.30 |
6.86 |
|
6×2.5 |
19/0.41 |
0.40 |
2.80 |
0.50 |
9.40 |
6.86 |
|
7×2.5 |
19/0.41 |
0.40 |
2.80 |
0.50 |
9.40 |
6.86 |
|
19×2.5 |
19/0.41 |
0.40 |
2.80 |
0.70 |
15.40 |
6.86 |
